●Features：
a) Full Range Sealing
For applications where a full-face flange is required,i.e. wafer and butterfly valves, the flange of the spigot piece provides a full flange sealing area.
b) Excellent Corrosion Protection
The flange adaptor and flange spigot are well coated, providing excellent protection from transport, storage, site and corrosion damage. The nuts and bolts are also perfectly coated, offering long term protection against corrosion.
c) Ultimate Sealing Capability
The EPDM gasket is compressed independently of the tie rods with the sealing capability secured as soon as the fasteners reach required torque.
d) Simple to Fit
Harnessing is accommodated within the bolt circle, eliminating other complex anchoring systems and reducing space requirements.
e) Wide Application
The simplicity and versatility of the fittings make them suitable for many applications including pumping stations, water treatment works, sewage treatment works, plant rooms, meter chambers, power generation equipment, gas distribution stations.
f) Easy Installation
Installation is extremely simple and is generally done with the flange adaptor end connected to the valve or other appurtenance. In cases where a full faced flange is required, for example on wafer butterfly valves, the joint is simply turned round to use the spigot flange instead.
●Standards: BS EN 4504, EN1092, ISO7005 or ANSI/AWWA B16.*
●Materials: Ductile iron(casted)
●Nominal sizes: DN50—2200mm
●Pressure: PN10/16/25/40, Class 125/150/250/300/*
●Corrosion protection: Inside and outside FBE 300um.
●Bolts and nuts: Carbon steel 4.8/8.8 or stainless steel 304/316.
●Gaskets: EPDM, SBR, NBR
●Package: Wooden case with plastic film, wooden pallets with
plastic film, steel crate.
PN10
|
DN |
D |
K |
b |
C |
L1 |
e± |
M×L |
d2 |
|
40 |
150 |
110 |
16 |
3 |
185 |
25 |
M16x300 |
φ19x4 |
|
50 |
165 |
125 |
16 |
3 |
185 |
25 |
M16 x300 |
φ19x4 |
|
65 |
185 |
145 |
16 |
3 |
185 |
25 |
M16 x300 |
φ19x4 |
|
80 |
200 |
160 |
16 |
3 |
210 |
30 |
M16 x330 |
φ19x8 |
|
100 |
220 |
180 |
16 |
3 |
215 |
30 |
M16 x330 |
φ19x8 |
|
125 |
250 |
210 |
16 |
3 |
210 |
25 |
M16 x330 |
φ19x8 |
|
150 |
285 |
240 |
16 |
3 |
215 |
30 |
M20x340 |
φ23x8 |
|
200 |
340 |
295 |
17 |
3 |
230 |
30 |
M20x360 |
φ23x8 |
|
250 |
400 |
355 |
19 |
3 |
225 |
30 |
M20x360 |
φ23x12 |
|
300 |
455 |
410 |
20.5 |
4 |
245 |
25 |
M20x380 |
φ23x12 |
|
350 |
505 |
470 |
20.5 |
4 |
260 |
30 |
M20x400 |
φ23x16 |
|
400 |
565 |
525 |
20.5 |
4 |
260 |
25 |
M24x410 |
Φ28x16 |
|
450 |
615 |
585 |
21.5 |
4 |
270 |
25 |
M24x420 |
Φ28x20 |
|
500 |
670 |
650 |
22.5 |
4 |
288 |
25 |
M24x430 |
Φ28x20 |
|
600 |
780 |
770 |
25 |
5 |
390 |
25 |
M27x460 |
φ31x20 |
|
700 |
895 |
840 |
27.5 |
5 |
300 |
25 |
M27x470 |
φ31x24 |
|
800 |
1015 |
950 |
30 |
5 |
300 |
25 |
M3x480 |
Φ34x24 |
|
900 |
1115 |
1050 |
32.5 |
5 |
310 |
25 |
M30x490 |
Φ34x28 |
|
1000 |
1230 |
1170 |
35 |
5 |
320 |
30 |
M33x520 |
Φ37x28 |
|
1100 |
1340 |
1270 |
37.5 |
5 |
320 |
30 |
M33x520 |
Φ37x32 |
|
1200 |
1455 |
1390 |
40 |
5 |
335 |
30 |
M36x550 |
φ40x32 |
|
1400 |
1675 |
1590 |
41 |
5 |
350 |
30 |
M39x570 |
Φ43x36 |
|
1500 |
1785 |
1710 |
42.5 |
5 |
375 |
35 |
M39x610 |
Φ43x36 |
|
1600 |
1915 |
1820 |
44 |
5 |
425 |
35 |
M45x670 |
Φ49x40 |
|
1800 |
2115 |
2020 |
47 |
5 |
430 |
40 |
M45x680 |
Φ49x44 |
|
2000 |
2325 |
2230 |
50 |
5 |
450 |
40 |
M45x710 |
Φ49x48 |
PN16
|
DN |
D |
K |
b |
C |
L1 |
e± |
M×L |
d2 |
|
40 |
150 |
110 |
16 |
3 |
185 |
25 |
M16x300 |
φ19x4 |
|
50 |
165 |
125 |
16 |
3 |
185 |
25 |
M16 x300 |
φ19x4 |
|
65 |
185 |
145 |
16 |
3 |
185 |
25 |
M16 x300 |
φ19x4 |
|
80 |
200 |
160 |
16 |
3 |
210 |
30 |
M16 x330 |
φ19x8 |
|
100 |
220 |
180 |
16 |
3 |
215 |
30 |
M16 x330 |
φ19x8 |
|
125 |
250 |
210 |
16 |
3 |
210 |
25 |
M16 x330 |
φ19x8 |
|
150 |
285 |
240 |
16 |
3 |
215 |
30 |
M20x340 |
φ23x8 |
|
200 |
340 |
295 |
17 |
3 |
230 |
30 |
M20x360 |
φ23x12 |
|
250 |
400 |
355 |
19 |
3 |
225 |
30 |
M24x370 |
φ28x12 |
|
300 |
455 |
410 |
20.5 |
4 |
255 |
30 |
M24x400 |
φ28x12 |
|
350 |
520 |
470 |
22.5 |
4 |
260 |
30 |
M24x420 |
φ28x16 |
|
400 |
580 |
525 |
24 |
4 |
275 |
30 |
M27x440 |
φ31x16 |
|
450 |
640 |
585 |
26 |
4 |
270 |
30 |
M27x440 |
φ31x20 |
|
500 |
715 |
650 |
27.5 |
4 |
285 |
30 |
M30x460 |
φ34x20 |
|
600 |
840 |
770 |
31 |
5 |
300 |
25 |
M33x490 |
φ37x20 |
|
700 |
910 |
840 |
34.5 |
5 |
300 |
25 |
M33x490 |
φ37x24 |
|
750 |
970 |
900 |
36 |
5 |
310 |
25 |
M33x510 |
φ37x24 |
|
800 |
1025 |
950 |
38 |
5 |
315 |
25 |
M36x520 |
φ40x24 |
|
900 |
1125 |
1050 |
41.5 |
5 |
320 |
25 |
M36x530 |
φ40x28 |
|
1000 |
1255 |
1170 |
45 |
5 |
340 |
25 |
M39x570 |
φ43x28 |
|
1100 |
1355 |
1270 |
48.5 |
5 |
340 |
25 |
M39x570 |
φ43x32 |
|
1200 |
1485 |
1390 |
52 |
5 |
360 |
25 |
M45x610 |
φ49x32 |
|
1400 |
1685 |
1590 |
55 |
5 |
375 |
30 |
M45x630 |
φ49x36 |
|
1500 |
1820 |
1710 |
57.5 |
5 |
410 |
30 |
M52x680 |
φ56x36 |
|
1600 |
1930 |
1820 |
60 |
5 |
450 |
40 |
M52x740 |
φ56x40 |
|
1800 |
2130 |
2020 |
65 |
5 |
460 |
40 |
M52x750 |
φ56x44 |
|
2000 |
2345 |
2230 |
70 |
5 |
485 |
50 |
M56x820 |
φ62x48 |
PN25
|
DN |
D |
K |
b |
C |
L1 |
e± |
M×L |
d2 |
|
80 |
200 |
160 |
16 |
3 |
215 |
25 |
M16 x330 |
φ19x8 |
|
100 |
235 |
190 |
16 |
3 |
215 |
25 |
M20 x340 |
Φ23x8 |
|
125 |
270 |
220 |
16 |
3 |
215 |
25 |
M24 x350 |
Φ28x8 |
|
150 |
300 |
250 |
17 |
3 |
215 |
25 |
M24x350 |
φ28x8 |
|
200 |
360 |
310 |
19 |
3 |
230 |
25 |
M24x370 |
φ28x12 |
|
250 |
425 |
370 |
21.5 |
3 |
235 |
25 |
M27x380 |
Φ31x12 |
|
300 |
485 |
430 |
23.5 |
4 |
260 |
25 |
M27x410 |
Φ31x16 |
|
350 |
555 |
490 |
26 |
4 |
270 |
25 |
M30x440 |
Φ34x16 |
|
400 |
620 |
550 |
28 |
4 |
280 |
25 |
M33x460 |
φ37x16 |
|
450 |
670 |
600 |
30.5 |
4 |
280 |
25 |
M33x460 |
φ37x20 |
|
500 |
730 |
660 |
32.5 |
4 |
290 |
25 |
M33x480 |
φ37x20 |
|
600 |
845 |
770 |
37 |
5 |
305 |
25 |
M36x510 |
Φ40x20 |
|
700 |
960 |
875 |
41.5 |
5 |
310 |
25 |
M39x530 |
Φ43x24 |
|
800 |
1085 |
990 |
46 |
5 |
325 |
25 |
M45x560 |
φ49x24 |
|
900 |
1185 |
1090 |
50.5 |
5 |
335 |
25 |
M45x580 |
φ49x28 |
|
1000 |
1320 |
1210 |
55 |
5 |
350 |
25 |
M52x620 |
Φ56x28 |
|
1200 |
1530 |
1420 |
64 |
5 |
410 |
25 |
M52x700 |
Φ56x32 |
|
1300 |
1645 |
1530 |
65.5 |
5 |
420 |
30 |
M56x720 |
Φ62x32 |
|
1400 |
1755 |
1640 |
69 |
5 |
450 |
30 |
M56x750 |
Φ62x36 |
|
1500 |
1865 |
1750 |
72.5 |
5 |
450 |
30 |
M56x760 |
Φ62x36 |
|
1600 |
1975 |
1860 |
76 |
5 |
475 |
40 |
M56x800 |
Φ62x40 |
|
1800 |
2195 |
2070 |
83 |
5 |
490 |
40 |
M64x840 |
Φ70x44 |
|
2000 |
2425 |
2300 |
90 |
5 |
510 |
40 |
M64x880 |
Φ70x48 |
